AVENTICS Series Valve Plug Connector Series CON-VP Industry Standard

Name: AVENTICS Series Valve Plug Connector Series CONVP Industry Standard
Brand: AVENTICS
Price: 255 USD

Brand Name : AVENTICS

Model Number : The AVENTICS Series CON-VP

MOQ : 1

Price : $255

Payment Terms : T/T

Supply Ability : 100

Packaging Details : Packaging and delivery Selling Units: Single item Single package size: 6X6X6 cm Single gross weight: 1.000 kg

Nominal Pressure : 2.5MPa

Rated Pressure : 315 bar

Pressure Rating : 150 PSI

Machinery Test Report : Provided

Valve Medium : Oil media

End Connection : Flanged

Flow Characteristic : Linear

Size : 1 inch

Seat Material : PTFE

Working Principle : high pressure ball valve

Applicable Industries : Cooling system

Body Material : Cast Iron

Face To Face Dimension : ASME B16.10

Type : High pressure ball valve

Trim Material : Stainless Steel

Contact Now

Product Description:

The AVENTICS Series CON - VP - with cable is a versatile solution for industrial connectivity. It provides valve plug connectors paired with cables in different lengths, making it easy to link various valve series and sensors. This series is highly compliant, covering connector types Form A, B, B Industry, C, and C Industry. These types adhere to well - known standards like EN 175301 - 803 (Form A), ISO 6952 (Form B), and ISO 15217 (Form C). Whether you're working on a complex factory automation system or a simple pneumatic setup, the CON - VP series ensures a reliable connection. It simplifies the process of integrating different components, making it a top choice for industries seeking seamless and standardized connectivity.

Product Features:

Valve plug connector with connected cable
Form A EN 175301-803
Form B ISO 6952 and B industry
Form C ISO 15217 and C industry
With/without protective circuit/LED

DESCRIPTION:

Cable length	3 m
Shielding	unshielded
Sealing material	caoutchouc/butadiene caoutchouc
Cable	with cable
Protection class	IP67
Number of wires	3-pin
Type	open cable ends

Ambient temperature min./max.	-20 … 80 °C
Operationalvoltage	See table
Protection class	IP67
Wire cross-section	0,75 mm²
Mounting screw tightening torque	0,4 Nm
Weight	See table

The specified protection class is only valid in assembled and tested state.

Material

Seals	caoutchouc/butadiene caoutchouc
Cable sheath	Polyvinyl chloride

roduct Details:

AVENTICS Series Valve Plug Connector Series CON-VP Industry Standard
